GPS/GNSS
NavX Horizon
₹15,000.00
₹10,000.00
-33% OFF
Inclusive of all taxes (GST)
In Stock
SKU: PA_NH_F10
Category: GPS/GNSS
Features
1. u-blox NEO-F10N High-Precision GNSS
2. Multi-Constellation Support (GPS, GLONASS, Galileo, BeiDou & NavIC Ready)
3. Built-in QMC5883L Digital Compass
4. High-Gain Ceramic Patch Antenna
5. Fast Satellite Lock & Stable Positioning
6. UART & I2C Communication Interfaces
7. Supports UBX & NMEA Protocols
8. Low Noise & High Sensitivity RF Design
9. Compact, Lightweight & Flight-Ready Design
10. Optimized for UAV, Rover & Robotics Applications
⸻
Specifications
1. GNSS Chipset: u-blox NEO-F10N
2. Input Voltage: 4V ~ 5V
3. Power Consumption: ~100mA
4. Default Baud Rate: 38400
5. Compass: QMC5883L
6. Interface: UART / I2C
7. Connector: JST-GH 6P
8. Operating Temperature: -20°C to 80°C
9. Weight: 15g
10. Protocol Support: UBX, NMEA
⸻
Compatible With
1. ArduPilot
2. INAV
3. Betaflight
4. PX4 Autopilot
1. u-blox NEO-F10N High-Precision GNSS
2. Multi-Constellation Support (GPS, GLONASS, Galileo, BeiDou & NavIC Ready)
3. Built-in QMC5883L Digital Compass
4. High-Gain Ceramic Patch Antenna
5. Fast Satellite Lock & Stable Positioning
6. UART & I2C Communication Interfaces
7. Supports UBX & NMEA Protocols
8. Low Noise & High Sensitivity RF Design
9. Compact, Lightweight & Flight-Ready Design
10. Optimized for UAV, Rover & Robotics Applications
⸻
Specifications
1. GNSS Chipset: u-blox NEO-F10N
2. Input Voltage: 4V ~ 5V
3. Power Consumption: ~100mA
4. Default Baud Rate: 38400
5. Compass: QMC5883L
6. Interface: UART / I2C
7. Connector: JST-GH 6P
8. Operating Temperature: -20°C to 80°C
9. Weight: 15g
10. Protocol Support: UBX, NMEA
⸻
Compatible With
1. ArduPilot
2. INAV
3. Betaflight
4. PX4 Autopilot
